✅ Key Features
- Selectable Transmit Power: 25mW / 1.6W / 2W / 2.5W / 3W
- 72 channels across 4990–5945 MHz frequency range
- Supports IRC Tramp Protocol for Betaflight OSD tuning
- OSD-based parameter control (no button needed)
- PAL & NTSC video formats supported
- MMCX antenna connector (SMA adapter included)
- Compact & lightweight: only 19g
📋 Specifications
| Product Name | VTX5830M |
|---|---|
| Transmit Power | 25mW / 1.6W / 2W / 2.5W / 3W |
| Default Output | 5.8GHz / 3W |
| Channels | 72CH |
| Frequency Range | 4990 – 5945 MHz |
| Video Format | PAL / NTSC |
| Antenna Connector | MMCX (SMA Adapter Included) |
| OSD Tuning | Supported |
| Protocol | IRC Tramp |
| Voltage Input | DC 7V – 28V |
| Dimensions | 53 × 31 × 14 mm |
| Mounting | 20mm x 20mm hole pitch |
| Weight | 19g |
| Built-in Microphone | No |
📦 Package Includes
- 1 × VTX5830M FPV Transmitter
- 1 × 8-Pin Connector Cable
- 1 × MMCX Female to SMA Female Adapter Cable (10cm)
🚀 Application
Perfect for:
- FPV Racing Drones
- Long Range Freestyle Builds
- Analog Video Transmission Setups
Compatible with most 5.8GHz FPV receivers and goggles.
