🔍 Key Features
- Uncooled Vanadium Oxide sensor for reliable performance
- 256×192 resolution with 12μm pixel pitch
- Wide lens: 50° Horizontal FOV
- Dual Output: CVBS (analog) + MIPI-CSI/Walksnail Avatar
- Panorama enhancement image quality optimization
- Ultra-low power: Less than 1.5W consumption
- Compact size & fast response with ~20ms latency
📊 Specifications
| Parameter | Value |
|---|---|
| Detector Type | Uncooled Vanadium Oxide |
| Resolution | 256×192 @12μm |
| Wavelength | 8 ~ 14μm |
| Lens | F1.0 / 4mm | FOV: 50°H x 37.2°V x 62.3°D |
| Frame Rate | 25 / 50 fps |
| Output | CVBS, MIPI-CSI / Walksnail Avatar |
| Latency | ~20ms |
| Power Supply | DC 5V–20V |
| Operating Temperature | -20℃ ~ 60℃ |
📦 Package Contents
- 1 × TIC256FM Thermal Imaging Camera
- 1 × 3-Pin Silicone Cable (150mm)
🔧 Ideal For
- UAV / Drone Integration
- Robotics Vision Systems
- Industrial Inspections
- Security & Surveillance
- Thermal Monitoring Solutions
