🚀 Key Features:
- Powered by STM32F722 MCU for superior processing capability
- Precision flight with ICM42688-P IMU and SPL06 barometer
- AT7456E chip for built-in OSD display
- Supports 3S–6S LiPo input with 5V-3A / 10V-2A BEC outputs
- DJI Air Unit connector ready for seamless digital FPV
- 6 UART interfaces for flexible peripheral integration
- Onboard 16MB Black Box for flight data logging
- Full support for GPS, ESC telemetry, WS2812 LED, compass, buzzer
📐 Specifications:
| Model | FC722-6S-X8M |
|---|---|
| MCU | STM32F722 |
| IMU | ICM42688-P |
| Barometer | SPL06 |
| OSD | AT7456E Chip |
| Black Box | Onboard 16MB |
| Bluetooth | NO |
| Dual-Camera Switch | YES |
| DJI Air Unit Connector | YES |
| Voltage Input | 3S-6S LiPo battery |
| BEC Output | 5V-3A / 10V-2A |
| USB Port | Type-C |
| UART Ports | UART1: VTX Data Setting UART2: Receiver (R2I for SBUS) UART3: GPS UART4: Custom Use UART5: ESC Telemetry UART6: Custom Use |
| ESC Signal | M1-M8 |
| I2C | YES (SDA & SCL for compass) |
| LED Pad | YES (WS2812 supported) |
| Buzzer Pad | YES |
| BOOT Button | YES |
| Firmware Target | STM32F722 |
| Mounting Pitch | 30.5 x 30.5 mm |
| Dimensions | 37 x 37 mm |
| Weight | 7g |
📦 Packing List:
- FC722-6S-X8M Flight Controller x1
- M3 Shock Balls x4
- 8pin Coaxial ESC Cable x1
- 3pin Camera Cable x1
- 4pin Receiver Cable x1
- 6pin GPS Cable x1
- 7pin Mapping Cable x1
💡 Applications:
Ideal for advanced FPV drones, long-range multirotors, and digital FPV systems requiring high processing power and DJI integration.
❓ Questions?
We’re happy to help! Message us through eBay for any pre-sale or technical inquiries.
