⚙️ Key Features:
- AT32F421K8U7 MCU – Fast and stable performance
- High-performance MOSFETs for power efficiency
- Supports 3–6S LiPo input voltage
- Continuous 60A current per channel, 65A peak
- Built-in ammeter with telemetry support
- DShot150 / DShot300 / DShot600 ESC protocols
- AM32 Firmware – Target: AM32_AT32DEV_F421_1.99
📊 Technical Specifications:
| Model | ESCAM60A-4IN1M |
|---|---|
| ESC MCU | AT32F421K8U7 |
| MOSFET | High-performance MOSFET |
| Input Voltage | 3S–6S LiPo Battery |
| Continuous Current | 60A × 4 |
| Peak Current | 65A (10 seconds) |
| Telemetry | YES |
| Ammeter | On-board |
| Current Sensor Scale | 270 |
| ESC Protocol | DShot150/300/600 |
| Firmware | AM32_AT32DEV_F421_1.99 |
| Mounting | 30.5 x 30.5mm |
| Dimensions | 44.5 x 40.5mm |
| Weight | 13.5g |
| Compatible Frames | HS-X07M / HS-X10M |
📦 Packing List:
- 1x ESCAM60A-4IN1M ESC
- 4x M3 Shock Balls
- 1x 8-Pin Coaxial ESC Connection Cable
- 4x M3*30 Socket Head Cap Screws
- 4x M3 Nylon Nuts
- 1x 35V 1000uF Capacitor
- 1x XT60 Connector (Male)
- 2x 12AWG Power Cables (10cm)
🛠️ Applications:
Perfect for high-performance racing drones, freestyle builds, and custom 3–6S quads demanding high burst current and reliable telemetry integration.
