⚙️ Features:
- AT32F421K8U7 MCU – Fast processing and stable signal response
- High-efficiency MOSFETs for minimal heat and maximum output
- Supports 3S–6S LiPo battery input
- Continuous current: 60A | Burst: 65A (10s)
- DShot150 / DShot300 / DShot600 protocols supported
- AM32 firmware ready – Target: AM32_AT32DEV_F421_1.99
- ESC telemetry supported for flight controller integration
📊 Technical Specifications:
| Model | ESCAM60A-SOLOM |
|---|---|
| ESC MCU | AT32F421K8U7 |
| MOSFET | High-performance type |
| Input Voltage | 3S–6S LiPo |
| Continuous Current | 60A |
| Peak Current | 65A (10 seconds) |
| ESC Telemetry | Yes |
| On-board Ammeter | No |
| ESC Protocols | DShot150 / 300 / 600 |
| Firmware | AM32_AT32DEV_F421_1.99 |
| Dimensions | 41 × 21 × 11 mm |
| Weight | 10.5g |
| FPV Compatibility | HS-P106M |
📦 Packing List:
- 1x ESCAM60A-SOLOM ESC
- 1x 35V 1000uF Capacitor
- 2x 14AWG Power Cables (150mm)
- 2x Signal Cables (150mm)
✅ Applications:
Ideal for lightweight racing drones, freestyle builds, and single-motor configurations that need smooth response and stable high-current delivery.
